PTC Creo Parametric

Course Length: 120 hours

This course is intended for Students and Working Professionals wanting to get introduced to the basic capabilities of Creo Parametric with a focus on Core Modeling Skills.

Topics include explanation of the User Interface along with understanding of the basic Creo Parametric concepts, Selection and Editing, Sketching and Sketcher Tools, and basic Feature creation. This course also includes a comprehensive design project that enables you to practice your new skills by creating realistic Parts.




Course Objectives

  • Learn the basic Creo Parametric Modeling process
  • Understand Creo Parametric concepts
  • Learn how to use the Creo Parametric interface
  • Select and edit geometry, features, and models
  • Sketch geometry and use tools
  • Create sketches for features
  • Create datum planes and datum axes
  • Create extrudes, revolves, and profile ribs
  • Utilize internal sketches and embedded datums
  • Create sweeps and blends
  • Create holes, shells, and drafts
  • Create rounds and chamfers
  • Complete the comprehensive design project





Prerequisites:


Basic Computer & Drawing knowledge


Training Session

Session1

Introduction to CAD

Features of Creo, Various products available in Creo for Product Design, Simulation and Communication.

Creo Graphical User Interface - Feature manager design tree, mouse buttons, keyboard shortcuts, Set up Units and File Management.

Session2

Sketch Tools - Centreline, Line, Circle, Arc, Ellipse, Rectangle, Spline, Points, Text and Palette.

Session3

Modify Tools - Fillet, Chamfer, Offset, Thicken, Project.

Editing Tools – Corner, Rotate RE-Size, Delete Segment, Mirror, Intersect, Divide and Modify.

Session4

Geometrical Constrain - Vertical, Horizontal, Perpendicular, Tangent, Mid – point, Coincident, Symmetric, Equal, Parallel.

Geometrical Dimension - Smart, Horizontal, Vertical, Ordinate, Horizontal ordinate, Vertical ordinate, Align ordinate, Fully define sketch.

GRAPHICS TOOL BAR

Session5

Part & Surface Modelling Tools

 Creating reference planes Creating

Extrude features – Direction1, Direction2, Thin feature and Applying draft.

Creating Revolve features – Selecting Axis, Thin features, Selecting contours.

Session6

Creating Swept feature – Sweep, Helix Sweep.

Creating Blend feature – Blend, Rotational Blend & Swept Blend

Creating Round feature – Round, Through Curve, Variable Round and Auto Round.

Creating Chamfer feature – Edge Chamfer and Corner Chamfer.

Session7

Creating Shell.

Creating Hole feature – Simple Hole & Standard Hole.

Creating Draft feature – Draft & Variable Pull Direction Draft.

Creating Rib feature – Trajectory Rib & Profile Rib.

Session8

Creating Pattern feature – Direction Pattern, Axis Pattern, Fill Pattern, Curve Pattern and Point Pattern.

Creating Mirror.

Session9

Advanced Part Modelling Tools

Engineering feature – Project, Toroidal Bend, Spinal Bend, Lattice

Editing feature – Wrap, Warp – Blend, Twist, Stretch and Tapper.

Session10

Advanced Surface Modelling Tools Merge, Boundary, Trim, Extend, Thicken, Fill, Vertex Round, Flatten Quilt and Flatten Quilt Deformation.

Session11

Generative design feature

Session12

Sheet Metal Design

Concepts in Sheet metal design bend allowance bend deduction, K-factor.

Inserting Planar & Extrude

Create Flat featureRectangle, Trapezoid, L – Shape, T – Shape and User – Define.

Create Flange feature - I – Shape, S – Shape, Open, Joggle, Duck, Arc, C – Shape, Z – Shape, Flushed and User – Define.

Session13

Create Wall feature – Revolve and Twist.

Create Bends feature – Bend, Bend Back, Unbend and Flat pattern.

Session14

Create Form feature - Punch Form, Die Form, Sketched Form.

Solid part converts to Sheet metal Add Feature – Edge Rip, Rip Connect, Surface Rip and Sketch Rip.

Session15

Assembling with Constraints – Distance, Angle Offset, Parallel, Coincident, Normal, Coplanar, Centred, Tangent and Fix.

Assembling with Connection – Pin, Slider, Ball, Cylinder and Slot.

Session16

Assembling with Mechanism – Gear, Belt and Cam.

Assembling with Exploding.

Simulation in Assemble Part.

Session17

Drafting Modelling Tools

Introduction to Drawing (Drafting )

Creating Drawing Views – Creating New Drawings and Applying Formats, Creating and Orienting General views, Adding Drawing Models and Sheets and Creating Projection Views.

Session18

Creating Drawing Views – Creating cross-section views, Creating Auxiliary views, Creating New Drawings using Drawing Templates, Modifying Drawing Views, Creating Assembly and Exploded Views.

Session19

Creating Drawing Details – Showing and Erasing Detail Items, Cleaning Up Dimensions and Manipulating Dimensions.

Creating Drawing Details – Creating Notes, Showing a Bill of Materials.

Session20

Rendering

Introduction to Photo Works, How to render model in Photo Works Studio? How to render specified area? How to save image to a specified file? How to edit scenery? How to apply back ground and base? Scene editor, How to apply material and decal? How to set camera and lights? Render options.
